4G Mobile DVR Designed for Passenger Coaches Buses Taxis and Dangerous Goods Vehicles with Stable Performance and Easy Operation
Detail produk:
| Tempat asal: | Shenzhen |
| Nama merek: | Oxiang /OEM |
| Sertifikasi: | CE.RoHS,FCC |
| Nomor model: | MD264 |
|
Informasi Detail |
|||
| Jaringan: | Wi-Fi 2,4GHz (IEEE 802.11 b/g/n) | LED Merah Berkedip: | Power OK, Menunggu Koneksi WiFi |
|---|---|---|---|
| Tipe Daya: | Baterai 18650 yang dapat diisi ulang atau kabel keras AC12V-24V | KONSUMSI: | Mode kerja: 170mA Mode Siaga: 200μA |
| Berat: | 600 g | Rentang Penjemputan: | 5 meter |
| Kelembaban Kerja: | <95% | Fungsi pesan: | Mendukung Fungsi Meninggalkan Pesan |
| Rana: | 1/25~1/100, 000 Per Detik | KELEMBABAN RELATIF: | 85% non-kondensasi |
| Jarak IR: | 3 meter | Sensor Gambar: | SC2335/SC233A |
| Sudut horizontal: | 140 sudut horizontal | Sudut deteksi: | 110° |
| Fungsi: | 3G/4G/GPS/WiFi | Kekuatan: | DC12V/2A |
| Pengaturan Gambar: | Mendukung cermin dukungan HD/SD | Tingkat tahan air: | IP55 |
| Kamera: | 1 mega piksel, OV9732 (sudut lebar 125°) | Sudut lebar: | 130 derajat |
| Ukuran Layar: | 7 inci | Resolusi Input Kamera: | AHD1080P/720P/CVBS |
| Jenis Sensor: | Penghitungan Video, akurasi 98%. | Dimensi tuan rumah: | 200(P) x187(L) x62(T) mm |
| Kompresi: | H.265 | Input tegangan: | beradaptasi dengan 8 hingga 36V ultra lebar |
| Dukungan perangkat lunak: | CMSV6 dan platform pribadi kami | Jaminan: | 12 bulan |
| SDK: | SDK gratis untuk pengembangan kedua | Unduhan WIFI: | Mendukung |
| Antarmuka Operasi: | Antarmuka Pengguna Grafis (menu OSD) | Kustomisasi: | Ya |
| Tahan air: | IP69K | Tahan kejut: | Anti-getaran ganda |
| Fungsi: | Penghitung orang, 3G, GPS, G-sensor, UPS | ||
| Menyoroti: | 4G mobile DVR for passenger coaches,4G mobile DVR for buses with stable performance,4G mobile DVR for dangerous goods vehicles |
||
Deskripsi Produk
4CH 4G WiFi HDD/SSD MDVR specification sheet
Model:OX-MD264
1.1 Product features
This series of products is a fully functional Hard Disk Driver 4G mobile DVR designed for the mobile surveillance market. Supports wide power voltage input, supports high-capacity HDD/SSD and TF card recording; Use professional and reliable aviation plug connector; High appearance, enough materials, good heat dissipation; The device has powerful functions, rich interfaces and low power consumption; Simple installation, easy operation, and extremely stable; widely used in passenger Coach, buses, taxis, school buses, logistics vehicles, dangerous goods vehicles, Sedan cars, ships, etc.
The detailed features are as follows:
- Industrial design, stable and reliable, easy to install
- Video adopts the international mainstream H.265 encoding format, and the audio adopts G711a encoding. It can support up to 4 channels.
- Professional vehicle power supply, can adapt to 8 to 36V ultra-wide voltage input, with multiple protection circuits such as overload/short circuit/reverse connection
- Highly reliable aviation plug input and output interface, easy to install and plug, and stronger Vandal-proof performance
- Support 4 channels of video and audio input, frame rate and image quality are adjustable
- Support 1x2.5inch HDD/SSD +1xTF Card Storage
- Built-in Farad capacitor. The video content has power-off protection function
- Support video loss alarm function
- Independent delay Power shutdown, can support the system to continue running after the vehicle is turned off, the delay time can be set by yourself
- Supporting CMS client platform, providing multiple functions such as playback, analysis, management, etc
- Support HDD/SSD, TF card and U disk to upgrade firmware, support network remote firmware upgrade.
- Supports 2 USB ports, the front can be connected to a USB drive to export videos or upgrade firmware, and the back can be connected to a fireproof box to backup videos
- Support 8 x IO alarm input, 2 x IO alarm output
- Support 2 x RS232 and 1 x RS485
- Insert the intercom handle for two-way communication between the platform and the device
- Support pulse vehicle speed. Optional
- Support 4G, GPS, LAN(RJ45)
- Optional WiFi function
